2. Mecdium temperature not more than +20c
3. PH value of medum is between 6.5-8.5
4. The deepest depth of submergence shall not exceed 20 m,and the shalowest depth shall not be less than5m
The company firmly believes that science and technology are the primary productive forces. Rely on quality for survival, rely on technological innovation for development.
+86-18869976464 Contact Us(Model) | Flow (m³/h) |
Lift (m) |
Power (Kw) |
Voltage (V) |
Frequency (Hz) |
Rotating speed (r/min) |
Piping (mm) |
QGD1.2-50-0.37 | 1.2 | 50 | 0.37 | 220 | 50 | 2860 | 25 |
QGD1.8-55-0.55 | 1.8 | 55 | 0.55 | 220 | 50 | 2860 | 25 |
QGD1.2-60-0.75 | 1.2 | 60 | 0.75 | 220 | 50 | 2860 | 25 |
QGD1.2-60-0.8 | 1.2 | 60 | 0.8 | 220 | 50 | 2860 | 25 |
QGD2-70-0.9 | 2 | 70 | 0.9 | 220 | 50 | 2860 | 25 |
QGD2-80-0.95 | 2 | 80 | 0.95 | 220 | 50 | 2860 | 25 |
QGD2-120-1.1 | 2 | 120 | 1.1 | 220 | 50 | 2860 | 25 |
QGD2-150-2.2 | 2 | 150 | 2.2 | 220 | 50 | 2860 | 25 |
100QJ(D)Y2-42/6-0.75 | 2 | 42 | 0.75 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-56/8-1.1 | 2 | 56 | 1.1 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-70/10-1.2 | 2 | 70 | 1.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-84/12-1.5 | 2 | 84 | 1.5 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-98/14-1.8 | 2 | 98 | 1.8 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-112/16-2.2 | 2 | 112 | 2.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(DJY2-126/18-2.5 | 2 | 126 | 2.5 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-140/20-2.8 | 2 | 140 | 2.8 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-161/23-3 | 2 | 161 | 3 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-175/25-3.2 | 2 | 175 | 3.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-210/30-4 | 2 | 210 | 4 | 220/380 | 50 | 2860 | 25/40 |
90QJ(DjY2-38/7-0.75 | 2 | 38 | 0.75 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y-50/9-1.1 | 2 | 50 | 1.1 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-60/11-1.2 | 2 | 60 | 1.2 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-72/13-1.5 | 2 | 72 | 1.5 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-82-15-1.5 | 2 | 82 | 1.8 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-93/17-2.2 | 2 | 93 | 2.2 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-105/19-2.5 | 2 | 105 | 2.5 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-120/22-2.8 | 2 | 120 | 2.8 | 220/380 | 50 | 2860 | 25/40 |
(VSm180F) CONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value
See DetailsCONDITION: Automatic;automatic controler is arranged in the direction of the pump outlet,the
See DetailsCONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value between 6.5~
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction
See Details1. Medum temperature not more than +40℃2. The pH value of the medum is between 6.5-8.53. The mass
See Details1. The volume ratio of solid impurities in the mecdium shall not exceed 0.1%, and the particle si
See DetailsMaterial Casing:Cast lron Impeller:Brass Shaft:Crstainless lron MSeal:Carbon&Ceramic High-tempe
See Details1.Medium temperature not more than +40℃2.Medilum pH value between 5 and 93.The volume ratio of sol
See Details1. The volume ratio of solid impurities in the mecdium shall not exceed 0.1%, and the particle size
See DetailsCONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value between 6.5~8
