Impeller:PP/Stainless Steel
Motor Housing:Aluminium
The company firmly believes that science and technology are the primary productive forces. Rely on quality for survival, rely on technological innovation for development.
+86-18869976464 Contact Us(Model) | Power (W) |
Voltage (V) |
Frequency (Hz) |
Connection size (IN) |
Rotating speed (r/min) |
Maximum lift (m) |
Maximum flow (L/min) |
Inlet/Outlet (IN) |
NW (Kg) |
LRS12/9-Z | 120 | 110-127 220-240 | 50/60 | 3/4*1/2" | 2580/3300 | 9 | 15 | ||
LRS12/11-2 | 200 | 110-127 220-240 | 50/60 | 3/4**1/2" | 2580/3300 | 11 | 20 | ||
LRS20/15-Z | 260 | 110-127 220-240 | 50/60 | 1**3/4" | 2580/3300 | 15 | 45 | ||
LRS12/9-ZG | 100 | 110-127 220-240 | 50/60 | 3/4**1/2" | 2520/3300 | 9 | 15 | ||
LRS15/9-ZG | 100 | 110-127 220-240 | 50/60 | 1"3/4" | 2520/3300 | 9 | 30 | ||
LRS15/12-ZG | 200 | 110-127 220-240 | 50/60 | 1*3/4" | 2520/3300 | 12 | 45 | ||
LRS15/15-ZG | 300 | 110-127 220-240 | 50/60 | 1*"3/4" | 2520/3300 | 15 | 55 | ||
LRS12/9-Z | 100 | 110-127220-240 | 50/60 | 3/4"X1/2" | 2520/3330 | 9 | 15 | ||
LRS15/9-Z | 100 | 110-127220-240 | 50/60 | 1"X3/4" | 2520/3330 | 9 | 30 | ||
LRS15/12-Z | 200 | 110-127220-240 | 50/60 | 1"X3/4" | 2520/3330 | 12 | 45 | ||
LRS15/15-Z | 300 | 110-127 220-240 | 50/60 | 1"X3/4" | 2520/3330 | 15 | 55 | ||
LRS15/4 | 72/53/38 | 4.5/4/3 | 39/29/18 | 1" | 2.1 | ||||
LRS25/4-130 | 72/53/38 | 4.5/4/3 | 49/35/21 | 1%" | 2.2 | ||||
LRS25/4-180 | 72/53/38 | 4.5/4/3 | 57/39/21 | 1%" | 2.4 | ||||
LRS32/4 | 72/53/38 | 4.5/4/3 | 66/44/22 | 2" | 2.6 | ||||
LRS15/6 | 93/67/46 | 2006/5/3 | 48/35/21 | 1" | 2.3 | ||||
LRS20/6 | 93/67/46 | 2006/5/3 | 55/38/22 | 1%" | 2.4 | ||||
LRS25/6-130 | 93/67/46 | 2006/5/3 | 55/38/22 | 1%" | 2.4 | ||||
LRS25/6-180 | 93/67/46 | 2006/5/3 | 69/48/26 | 1%" | 2.6 | ||||
LRS32/6 | 93/67/46 | 2006/5/3 | 70/48/26 | 2" | 2.8 | ||||
LRS15/7 | 135/93/67 | 2007/6/5 | 55/45/29 | 1" | 2.6 | ||||
LRS25/7-130 | 135/93/67 | 7/6.5/4.5 | 64/51/32 | 1%" | 2.8 | ||||
LRS26/7-180 | 135/93/67 | 7/6.5/4.5 | 69/54/35 | 1%" | 2.9 | ||||
LRS32/7 | 135/93/67 | 7/6.5/4.5 | 70/56/36 | 2" | 3.1 | ||||
LRS15/8 | 165/115/75 | 2008/7/5 | 65/42/22 | 1" | 3.3 | ||||
LRS15/8 | 165/115/75 | 2008/7/5 | 98/63/36 | 1%" | 3.4 | ||||
LRS25/8 | 270/210/150 | 8/7.5/65 | 160/103/43 | 2" | 4.8 | ||||
LRS32/8 | 165/115/75 | 11/7/3.4 | 35/20/10 | 1" | 3.9 | ||||
LRS20/11 | 245/220/145 | 2012/11/7 | 52/32/22 | 1" | 4.5 | ||||
LRS20/12 | 245/220/145 | 2012/11/7 | 62/37/23 | 1%" | 4.5 | ||||
LRS25/12 | 270/210/150 | 14/13/10 | 68/48/28 | 1%" | 5.1 |
Pump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsCONDITION 1.Medium temperature is not more than +40 DEGC2.Medium PH value between 6.5~8.53.Contain
See DetailsCONDITION 1.Medium temperature is not more than +40 DEGC2.Medium PH value between 6.5~8.53.Contai
See DetailsCONDITION 1.Medium temperature is not more than +40 DEGC2.Medium PH value between 6.5~8.53.Conta
See DetailsCONDITION 1.Medium temperature is not more than +40 DEGC2.Medium PH value between 6.5~8.53.Cont
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction
See DetailsZhejiang Shuyilin Electromechanical Co., Ltd. is a modern new-type water pumps manufacturing enterprise specializing in production, scientific research, development, sales and service.
