2. Mecdium temperature not more than +20c
3. PH value of medum is between 6.5-8.5
4. The deepest depth of submergence shall not exceed 20 m,and the shalowest depth shall not be less than5m
The company firmly believes that science and technology are the primary productive forces. Rely on quality for survival, rely on technological innovation for development.
+86-18869976464 Contact Us(Model) | Flow (m³/h) |
Lift (m) |
Power (Kw) |
Voltage (V) |
Frequency (Hz) |
Rotating speed (r/min) |
Piping (mm) |
QGD1.2-50-0.37 | 1.2 | 50 | 0.37 | 220 | 50 | 2860 | 25 |
QGD1.8-55-0.55 | 1.8 | 55 | 0.55 | 220 | 50 | 2860 | 25 |
QGD1.2-60-0.75 | 1.2 | 60 | 0.75 | 220 | 50 | 2860 | 25 |
QGD1.2-60-0.8 | 1.2 | 60 | 0.8 | 220 | 50 | 2860 | 25 |
QGD2-70-0.9 | 2 | 70 | 0.9 | 220 | 50 | 2860 | 25 |
QGD2-80-0.95 | 2 | 80 | 0.95 | 220 | 50 | 2860 | 25 |
QGD2-120-1.1 | 2 | 120 | 1.1 | 220 | 50 | 2860 | 25 |
QGD2-150-2.2 | 2 | 150 | 2.2 | 220 | 50 | 2860 | 25 |
100QJ(D)Y2-42/6-0.75 | 2 | 42 | 0.75 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-56/8-1.1 | 2 | 56 | 1.1 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-70/10-1.2 | 2 | 70 | 1.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-84/12-1.5 | 2 | 84 | 1.5 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-98/14-1.8 | 2 | 98 | 1.8 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-112/16-2.2 | 2 | 112 | 2.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(DJY2-126/18-2.5 | 2 | 126 | 2.5 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-140/20-2.8 | 2 | 140 | 2.8 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-161/23-3 | 2 | 161 | 3 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-175/25-3.2 | 2 | 175 | 3.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-210/30-4 | 2 | 210 | 4 | 220/380 | 50 | 2860 | 25/40 |
90QJ(DjY2-38/7-0.75 | 2 | 38 | 0.75 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y-50/9-1.1 | 2 | 50 | 1.1 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-60/11-1.2 | 2 | 60 | 1.2 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-72/13-1.5 | 2 | 72 | 1.5 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-82-15-1.5 | 2 | 82 | 1.8 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-93/17-2.2 | 2 | 93 | 2.2 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-105/19-2.5 | 2 | 105 | 2.5 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-120/22-2.8 | 2 | 120 | 2.8 | 220/380 | 50 | 2860 | 25/40 |
Pump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsCONDITION 1.Medium temperature is not more than +40 DEGC2.Medium PH value between 6.5~8.53.Cont
See DetailsCONDITION 1.Ring medium temperature≤40℃2.Medium pH value is 6.5-8.53.The volume ratio of solid i
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction
See DetailsPerformance Range Flow rate up to 80L/min(4.8m2/h) Head upto 55m Operating Limits: Suction lif
See DetailsPerformance Range Flow rate up to 80L/min(4.8m2/h) Head upto 55m Operating Limits: Suction l
See DetailsMaterial Casing:Cast lron Impeller:Brass Shaft:Crstainless lron MSeal:Carbon&Ceramic High-temp
See DetailsMaterial Casing:Cast lron Impeller:Brass Shaft:Crstainless lron MSeal:Carbon&Ceramic High-tem
See DetailsZhejiang Shuyilin Electromechanical Co., Ltd. is a modern new-type water pumps manufacturing enterprise specializing in production, scientific research, development, sales and service.
