2. Mecdium temperature not more than +20c
3. PH value of medum is between 6.5-8.5
4. The deepest depth of submergence shall not exceed 20 m,and the shalowest depth shall not be less than5m
The company firmly believes that science and technology are the primary productive forces. Rely on quality for survival, rely on technological innovation for development.
+86-18869976464 Contact Us(Model) | Flow (m³/h) |
Lift (m) |
Power (Kw) |
Voltage (V) |
Frequency (Hz) |
Rotating speed (r/min) |
Piping (mm) |
QGD1.2-50-0.37 | 1.2 | 50 | 0.37 | 220 | 50 | 2860 | 25 |
QGD1.8-55-0.55 | 1.8 | 55 | 0.55 | 220 | 50 | 2860 | 25 |
QGD1.2-60-0.75 | 1.2 | 60 | 0.75 | 220 | 50 | 2860 | 25 |
QGD1.2-60-0.8 | 1.2 | 60 | 0.8 | 220 | 50 | 2860 | 25 |
QGD2-70-0.9 | 2 | 70 | 0.9 | 220 | 50 | 2860 | 25 |
QGD2-80-0.95 | 2 | 80 | 0.95 | 220 | 50 | 2860 | 25 |
QGD2-120-1.1 | 2 | 120 | 1.1 | 220 | 50 | 2860 | 25 |
QGD2-150-2.2 | 2 | 150 | 2.2 | 220 | 50 | 2860 | 25 |
100QJ(D)Y2-42/6-0.75 | 2 | 42 | 0.75 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-56/8-1.1 | 2 | 56 | 1.1 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-70/10-1.2 | 2 | 70 | 1.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-84/12-1.5 | 2 | 84 | 1.5 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-98/14-1.8 | 2 | 98 | 1.8 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-112/16-2.2 | 2 | 112 | 2.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(DJY2-126/18-2.5 | 2 | 126 | 2.5 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-140/20-2.8 | 2 | 140 | 2.8 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-161/23-3 | 2 | 161 | 3 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-175/25-3.2 | 2 | 175 | 3.2 | 220/380 | 50 | 2860 | 25/40 |
100QJ(D)Y2-210/30-4 | 2 | 210 | 4 | 220/380 | 50 | 2860 | 25/40 |
90QJ(DjY2-38/7-0.75 | 2 | 38 | 0.75 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y-50/9-1.1 | 2 | 50 | 1.1 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-60/11-1.2 | 2 | 60 | 1.2 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-72/13-1.5 | 2 | 72 | 1.5 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-82-15-1.5 | 2 | 82 | 1.8 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-93/17-2.2 | 2 | 93 | 2.2 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-105/19-2.5 | 2 | 105 | 2.5 | 220/380 | 50 | 2860 | 25/40 |
90QJ(D)Y2-120/22-2.8 | 2 | 120 | 2.8 | 220/380 | 50 | 2860 | 25/40 |
1. Medum temperature not more than +40℃2. The pH value of the medum is between 6.5-8.53. The mass
See DetailsCONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value between 6.5~8.
See Details1.Medium temperature not more than +40℃2.Medilum pH value between 5 and 93.The volume ratio of sol
See Details1.Medium temperature not more than +40℃2.Medilum pH value between 5 and 93.The volume ratio of sol
See DetailsCONDITION: 1.the maximum working pressure of the system is1.6Mpa2.foreign solids volume not exceed
See DetailsMaterial: Pumo body:Cast iron(HT200) Motor support:Aluminum Impeller:Brass Motor shaft:CS 45#o
See Details1.Medium temperature is not more than +40 DEGC2、Medium pH value between 6.5~8.53.Containing solid
See DetailsCONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value between 6.5
See DetailsCONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value between 6.5~8.53.
