2.Medilum pH value between 5 and 9
3.The volume ratio of solid impuritles in the medium shall not exceed 2%
4.Maximum diving depth not exceeding 5m
5.The operation time of motor dehydration should not be too long
The company firmly believes that science and technology are the primary productive forces. Rely on quality for survival, rely on technological innovation for development.
+86-18869976464 Contact Us(Model) | Flow (m³/h) |
Lift (m) |
Power (Kw) |
Voltage (V) |
Frequency (Hz) |
Rotating speed (r/min) |
Piping (mm) |
50JYWQD10-10-1000-0.75 | 10 | 10 | 0.75 | 220 | 50 | 1000 | 50 |
50JYWQ10-10-1000-0.75 | 10 | 10 | 0.75 | 380 | 50 | 1000 | 50 |
50JYWQD7-15-1200-1.1 | 7 | 15 | 1.1 | 220 | 50 | 1200 | 50 |
50JYWQ7-15-1200-1.1 | 7 | 15 | 1.1 | 380 | 50 | 1200 | 50 |
65JYWQD15-9-1200-1.1 | 15 | 9 | 1.1 | 220 | 50 | 1200 | 65 |
65JYWQ15-9-1200-1.1 | 15 | 9 | 1.1 | 380 | 50 | 1200 | 65 |
50JYWQD15-15-1200-1.5 | 15 | 15 | 1.5 | 220 | 50 | 1200 | 50 |
50JYWQ15-15-1200-1.5 | 15 | 15 | 1.5 | 380 | 50 | 1200 | 50 |
65JYWQD25-10-1200-1.5 | 25 | 10 | 1.5 | 380 | 50 | 1200 | 65 |
65JYWQ25-10-1200-1.5 | 25 | 10 | 1.5 | 380 | 50 | 1200 | 65 |
50JYWQ9-22-1600-2.2 | 9 | 22 | 2.2 | 380 | 50 | 1600 | 50 |
65JYWQ25-15-1600-2.2 | 25 | 12 | 2.2 | 380 | 50 | 1600 | 65 |
80JYWQ40-10-1600-2.2 | 40 | 10 | 2.2 | 380 | 50 | 1600 | 80 |
100JYWQ50-7-1600-2.2 | 50 | 7 | 2.2 | 380 | 50 | 1600 | 100 |
50JYWQ15-30-1600-3 | 15 | 30 | 3 | 380 | 50 | 1600 | 50 |
65JYWQ20-30-1600-4 | 20 | 30 | 4 | 380 | 50 | 1600 | 65 |
80JYWQ40-15-1600-4 | 40 | 15 | 4 | 380 | 50 | 1600 | 80 |
100JYWQ60-10-1600-4 | 60 | 10 | 4 | 380 | 50 | 1600 | 100 |
50JYWQ15-40-1600-5.5 | 15 | 40 | 5.5 | 380 | 50 | 1600 | 50 |
65JYWQ25-35-1600-5.5 | 25 | 35 | 5.5 | 380 | 50 | 1600 | 65 |
80JYWQ30-30-1600-5.5 | 30 | 30 | 5.5 | 380 | 50 | 1600 | 80 |
100JYWQ70-10-1600-5.5 | 70 | 10 | 5.5 | 380 | 50 | 1600 | 100 |
150JYWQ100-7-1600-5.5 | 100 | 7 | 5.5 | 380 | 50 | 1600 | 150 |
50JYWQ15-45-1600-7.5 | 15 | 45 | 7.5 | 380 | 50 | 1600 | 50 |
65JWYQ25-40-1600-7.5 | 25 | 40 | 7.5 | 380 | 50 | 1600 | 65 |
80JYWQ65-22-1600-7.5 | 65 | 22 | 7.5 | 380 | 50 | 1600 | 80 |
100JYWQ80-20-1600-7.5 | 80 | 20 | 7.5 | 380 | 50 | 1600 | 100 |
150JYWQ100-10-1600-7.5 | 100 | 10 | 7.5 | 380 | 50 | 1600 | 150 |
WQD6-16-0.75 | 6 | 16 | 0.75 | 220 | 50 | 2860 | 50 |
WQ6-16-0.75 | 6 | 16 | 0.75 | 380 | 50 | 2860 | 50 |
WQD8-18-1.1 | 8 | 18 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-18-1.1 | 8 | 18 | 1.1 | 380 | 50 | 2860 | 50 |
WQD8-16-1.1 | 8 | 16 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-16-1.1 | 8 | 16 | 1.1 | 380 | 50 | 2860 | 50 |
WQD8-26-1.1 | 8 | 26 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-26-1.1 | 8 | 26 | 1.1 | 380 | 50 | 2860 | 50 |
WQD10-16-1.1 | 10 | 16 | 1.1 | 220 | 50 | 2860 | 50 |
WQ10-16-1.1 | 10 | 16 | 1.1 | 380 | 50 | 2860 | 50 |
WQD12-18-1.5 | 12 | 18 | 1.5 | 220 | 50 | 2860 | 50 |
WQ12-18-1.5 | 12 | 18 | 1.5 | 380 | 50 | 2860 | 50 |
WQ015-18-1.5 | 15 | 18 | 1.5 | 220 | 50 | 2860 | 50 |
WQ15-18-1.5 | 15 | 18 | 1.5 | 380 | 50 | 2860 | 50 |
WQD8-20-1.5 | 8 | 20 | 1.5 | 220 | 50 | 2860 | 50 |
WQ8-20-1.5 | 8 | 20 | 1.5 | 380 | 50 | 2860 | 50 |
WQD15-15-1.5 | 15 | 15 | 1.5 | 220 | 50 | 2860 | 65 |
WQ15-15-1.5 | 15 | 15 | 1.5 | 380 | 50 | 2860 | 65 |
WQD30-10-1.5 | 30 | 10 | 1.5 | 220 | 50 | 2860 | 75 |
WQ30-10-1.5 | 30 | 10 | 1.5 | 380 | 50 | 2860 | 75 |
WQD8-40-1.5 | 8 | 40 | 1.5 | 220 | 50 | 2860 | 50 |
WQ8-40-1.5 | 8 | 40 | 1.5 | 380 | 50 | 2860 | 50 |
WQ10-30-2.2 | 10 | 30 | 2.2 | 380 | 50 | 3000 | 50 |
WQ15-32-2.2 | 15 | 32 | 2.2 | 380 | 50 | 3000 | 50 |
WQ20-25-2.2 | 20 | 25 | 2.2 | 380 | 50 | 3000 | 65 |
WQ30-15-2.2 | 30 | 15 | 2.2 | 380 | 50 | 3000 | 75 |
WQ15-36-3 | 15 | 36 | 3 | 380 | 50 | 3000 | 50 |
WQK10-10-0.75QG | 10 | 10 | 0.75 | 220/380 | 50 | 2860 | 50 |
WQK15-9-1.10G | 15 | 9 | 1.1 | 220/380 | 50 | 2860 | 50 |
WQK15-15-1.50G | 15 | 15 | 1.5 | 220/380 | 50 | 2860 | 50 |
WQK26-7-1.50G | 26 | 7 | 1.5 | 220/380 | 50 | 2860 | 80 |
WQK18-20-2.20G | 18 | 20 | 2.2 | 380 | 50 | 2860 | 50 |
WQK25-15-2.20G | 25 | 15 | 2.2 | 380 | 50 | 2860 | 65 |
WQK30-10-2.20G | 30 | 10 | 2.2 | 380 | 50 | 2860 | 80 |
WQK20-25-3QG | 20 | 25 | 3 | 380 | 50 | 2860 | 50 |
WQK30-16-3QG | 30 | 16 | 3 | 380 | 50 | 2860 | 65 |
WQK35-15-3QG | 35 | 15 | 3 | 380 | 50 | 2860 | 80 |
WQK40-13-3QG | 40 | 13 | 3 | 380 | 50 | 2860 | 100 |
WQK25-28-4QG | 25 | 28 | 4 | 380 | 50 | 2860 | 50 |
WQK32-20-4QG | 32 | 20 | 4 | 380 | 50 | 2860 | 65 |
WQK42-16-4QG | 42 | 16 | 4 | 380 | 50 | 2860 | 80 |
WOK50-12-4QG | 50 | 12 | 4 | 380 | 50 | 2860 | 100 |
WQK25-40-5.5QG | 25 | 40 | 5.5 | 380 | 50 | 2860 | 50 |
WQK40-28-5.5QG | 40 | 28 | 5.5 | 380 | 50 | 2860 | 65 |
WQK60-18-5.5QG | 60 | 18 | 5.5 | 380 | 50 | 2860 | 80 |
WQK80-10-5.5QG | 80 | 10 | 5.5 | 380 | 50 | 2860 | 100 |
WQK50-22-7.5QG | 50 | 22 | 7.5 | 380 | 50 | 2860 | 80 |
WQK80-20-7.5QG | 80 | 20 | 7.5 | 380 | 50 | 2860 | 100 |
QX8-40-1.5 | 8 | 40 | 1.5 | 220/380 | 50 | 2860 | 50 |
QX10-35-2.2 | 10 | 35 | 2.2 | 380 | 50 | 2860 | 50 |
QX10-45-3 | 10 | 45 | 3 | 380 | 50 | 2860 | 50 |
QX12-50-4 | 12 | 50 | 4 | 380 | 50 | 2860 | 50 |
QX12.5-60-5.5 | 12.5 | 60 | 5.5 | 380 | 50 | 2860 | 50 |
QX15-68-7.5 | 15 | 68 | 7.5 | 380 | 50 | 2860 | 50 |
Pump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Ste
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless St
See DetailsCONDITION 1.Medium temperature is not more than +40 DEGC2.Medium PH value between 6.5~8.53.Conta
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction l
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction
