Material
Casing:Cast lron
Impeller:Brass
Shaft:Crstainless lron
MSeal:Carbon&Ceramic
High-temperature bearing Bearing:NSK
Technical Date：
Liquid:Clean Water
Power Source：1-220v-50HZ
Fluid Temp：0℃ to+110℃
Ambient Temp:Up to+40℃
|
（Model） |
Power (W) |
Volt (V/Hz) |
Speed (r/min) |
Max Flow (l/min) |
Max Delivery (m) |
Sact Lift (m) |
Inlet/outlet （mm） |
Weight （kg） |
|
25WZB-15-125A |
125 |
220,50Hz |
2860 |
25 |
20 |
8 |
25（1"） |
10.5 |
|
25WZB-15-200A |
200 |
220,50Hz |
2860 |
28 |
25 |
8 |
25（1"） |
11.5 |
|
25WZB-18-300A |
300 |
220,50Hz |
2860 |
30 |
30 |
8 |
25（1"） |
12 |
|
25WZB-20-400A |
400 |
220,50Hz |
2860 |
35 |
35 |
8 |
25（1"） |
13.8 |
|
25WZB-23-600A |
600 |
220,50Hz |
2860 |
40 |
40 |
8 |
25（1"） |
14 |
|
25WZB-25-800A |
800 |
220,50Hz |
2860 |
45 |
45 |
8 |
25（1"） |
16.7 |
|
25WZB-28-1100A |
1100 |
220,50Hz |
2860 |
50 |
50 |
8 |
40（1½"） |
17 |
Company Profile
Zhejiang Shuyilin Electromechanical Co., Ltd.Our Company Mainly Deals In Water Pumps.The company has many years of experience in the production of small, WZB automatic cold and hot self-priming pump-(2) and medium-sized motor water pumps.The product specifications are complete and diverse, the design is advanced, the materials are selected, the technology is advanced and unique, and it has the advantages of excellent performance, safe and reliable use, and durability. It has won unanimous praise from customers at home and abroad.
The company mainly produces submersible pumps, deep well pumps, sewage pumps, self-priming pumps, screw pumps, multi-stage submersible pumps, canned motor pumps and more than a dozen series and more than 300 products.All national standard motors, the head and flow are actually marked, the movement adopts high-grade all copper wire and cold-rolled silicon steel strip, wide voltage, low temperature rise, longer life, higher efficiency, and more power! Long-lasting uninterrupted operation without pressure!
