2、Medium pH value between 6.5~8.5
3.Containing solid impurities in the medium volume ratio of not more than 0.1%
4、Diving depth of up to 100m
5、Pump professional sewage pumping
The company firmly believes that science and technology are the primary productive forces. Rely on quality for survival, rely on technological innovation for development.
+86-18869976464 Contact Us(Model) | Flow (m³/h) |
Lift (m) |
Power (Kw) |
Voltage (V) |
Frequency (Hz) |
Rotating speed (r/min) |
Piping (mm) |
50JYWQD10-10-1000-0.75 | 10 | 10 | 0.75 | 220 | 50 | 1000 | 50 |
50JYWQ10-10-1000-0.75 | 10 | 10 | 0.75 | 380 | 50 | 1000 | 50 |
50JYWQD7-15-1200-1.1 | 7 | 15 | 1.1 | 220 | 50 | 1200 | 50 |
50JYWQ7-15-1200-1.1 | 7 | 15 | 1.1 | 380 | 50 | 1200 | 50 |
65JYWQD15-9-1200-1.1 | 15 | 9 | 1.1 | 220 | 50 | 1200 | 65 |
65JYWQ15-9-1200-1.1 | 15 | 9 | 1.1 | 380 | 50 | 1200 | 65 |
50JYWQD15-15-1200-1.5 | 15 | 15 | 1.5 | 220 | 50 | 1200 | 50 |
50JYWQ15-15-1200-1.5 | 15 | 15 | 1.5 | 380 | 50 | 1200 | 50 |
65JYWQD25-10-1200-1.5 | 25 | 10 | 1.5 | 380 | 50 | 1200 | 65 |
65JYWQ25-10-1200-1.5 | 25 | 10 | 1.5 | 380 | 50 | 1200 | 65 |
50JYWQ9-22-1600-2.2 | 9 | 22 | 2.2 | 380 | 50 | 1600 | 50 |
65JYWQ25-15-1600-2.2 | 25 | 12 | 2.2 | 380 | 50 | 1600 | 65 |
80JYWQ40-10-1600-2.2 | 40 | 10 | 2.2 | 380 | 50 | 1600 | 80 |
100JYWQ50-7-1600-2.2 | 50 | 7 | 2.2 | 380 | 50 | 1600 | 100 |
50JYWQ15-30-1600-3 | 15 | 30 | 3 | 380 | 50 | 1600 | 50 |
65JYWQ20-30-1600-4 | 20 | 30 | 4 | 380 | 50 | 1600 | 65 |
80JYWQ40-15-1600-4 | 40 | 15 | 4 | 380 | 50 | 1600 | 80 |
100JYWQ60-10-1600-4 | 60 | 10 | 4 | 380 | 50 | 1600 | 100 |
50JYWQ15-40-1600-5.5 | 15 | 40 | 5.5 | 380 | 50 | 1600 | 50 |
65JYWQ25-35-1600-5.5 | 25 | 35 | 5.5 | 380 | 50 | 1600 | 65 |
80JYWQ30-30-1600-5.5 | 30 | 30 | 5.5 | 380 | 50 | 1600 | 80 |
100JYWQ70-10-1600-5.5 | 70 | 10 | 5.5 | 380 | 50 | 1600 | 100 |
150JYWQ100-7-1600-5.5 | 100 | 7 | 5.5 | 380 | 50 | 1600 | 150 |
50JYWQ15-45-1600-7.5 | 15 | 45 | 7.5 | 380 | 50 | 1600 | 50 |
65JWYQ25-40-1600-7.5 | 25 | 40 | 7.5 | 380 | 50 | 1600 | 65 |
80JYWQ65-22-1600-7.5 | 65 | 22 | 7.5 | 380 | 50 | 1600 | 80 |
100JYWQ80-20-1600-7.5 | 80 | 20 | 7.5 | 380 | 50 | 1600 | 100 |
150JYWQ100-10-1600-7.5 | 100 | 10 | 7.5 | 380 | 50 | 1600 | 150 |
WQD6-16-0.75 | 6 | 16 | 0.75 | 220 | 50 | 2860 | 50 |
WQ6-16-0.75 | 6 | 16 | 0.75 | 380 | 50 | 2860 | 50 |
WQD8-18-1.1 | 8 | 18 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-18-1.1 | 8 | 18 | 1.1 | 380 | 50 | 2860 | 50 |
WQD8-16-1.1 | 8 | 16 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-16-1.1 | 8 | 16 | 1.1 | 380 | 50 | 2860 | 50 |
WQD8-26-1.1 | 8 | 26 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-26-1.1 | 8 | 26 | 1.1 | 380 | 50 | 2860 | 50 |
WQD10-16-1.1 | 10 | 16 | 1.1 | 220 | 50 | 2860 | 50 |
WQ10-16-1.1 | 10 | 16 | 1.1 | 380 | 50 | 2860 | 50 |
WQD12-18-1.5 | 12 | 18 | 1.5 | 220 | 50 | 2860 | 50 |
WQ12-18-1.5 | 12 | 18 | 1.5 | 380 | 50 | 2860 | 50 |
WQ015-18-1.5 | 15 | 18 | 1.5 | 220 | 50 | 2860 | 50 |
WQ15-18-1.5 | 15 | 18 | 1.5 | 380 | 50 | 2860 | 50 |
WQD8-20-1.5 | 8 | 20 | 1.5 | 220 | 50 | 2860 | 50 |
WQ8-20-1.5 | 8 | 20 | 1.5 | 380 | 50 | 2860 | 50 |
WQD15-15-1.5 | 15 | 15 | 1.5 | 220 | 50 | 2860 | 65 |
WQ15-15-1.5 | 15 | 15 | 1.5 | 380 | 50 | 2860 | 65 |
WQD30-10-1.5 | 30 | 10 | 1.5 | 220 | 50 | 2860 | 75 |
WQ30-10-1.5 | 30 | 10 | 1.5 | 380 | 50 | 2860 | 75 |
WQD8-40-1.5 | 8 | 40 | 1.5 | 220 | 50 | 2860 | 50 |
WQ8-40-1.5 | 8 | 40 | 1.5 | 380 | 50 | 2860 | 50 |
WQ10-30-2.2 | 10 | 30 | 2.2 | 380 | 50 | 3000 | 50 |
WQ15-32-2.2 | 15 | 32 | 2.2 | 380 | 50 | 3000 | 50 |
WQ20-25-2.2 | 20 | 25 | 2.2 | 380 | 50 | 3000 | 65 |
WQ30-15-2.2 | 30 | 15 | 2.2 | 380 | 50 | 3000 | 75 |
WQ15-36-3 | 15 | 36 | 3 | 380 | 50 | 3000 | 50 |
WQK10-10-0.75QG | 10 | 10 | 0.75 | 220/380 | 50 | 2860 | 50 |
WQK15-9-1.10G | 15 | 9 | 1.1 | 220/380 | 50 | 2860 | 50 |
WQK15-15-1.50G | 15 | 15 | 1.5 | 220/380 | 50 | 2860 | 50 |
WQK26-7-1.50G | 26 | 7 | 1.5 | 220/380 | 50 | 2860 | 80 |
WQK18-20-2.20G | 18 | 20 | 2.2 | 380 | 50 | 2860 | 50 |
WQK25-15-2.20G | 25 | 15 | 2.2 | 380 | 50 | 2860 | 65 |
WQK30-10-2.20G | 30 | 10 | 2.2 | 380 | 50 | 2860 | 80 |
WQK20-25-3QG | 20 | 25 | 3 | 380 | 50 | 2860 | 50 |
WQK30-16-3QG | 30 | 16 | 3 | 380 | 50 | 2860 | 65 |
WQK35-15-3QG | 35 | 15 | 3 | 380 | 50 | 2860 | 80 |
WQK40-13-3QG | 40 | 13 | 3 | 380 | 50 | 2860 | 100 |
WQK25-28-4QG | 25 | 28 | 4 | 380 | 50 | 2860 | 50 |
WQK32-20-4QG | 32 | 20 | 4 | 380 | 50 | 2860 | 65 |
WQK42-16-4QG | 42 | 16 | 4 | 380 | 50 | 2860 | 80 |
WOK50-12-4QG | 50 | 12 | 4 | 380 | 50 | 2860 | 100 |
WQK25-40-5.5QG | 25 | 40 | 5.5 | 380 | 50 | 2860 | 50 |
WQK40-28-5.5QG | 40 | 28 | 5.5 | 380 | 50 | 2860 | 65 |
WQK60-18-5.5QG | 60 | 18 | 5.5 | 380 | 50 | 2860 | 80 |
WQK80-10-5.5QG | 80 | 10 | 5.5 | 380 | 50 | 2860 | 100 |
WQK50-22-7.5QG | 50 | 22 | 7.5 | 380 | 50 | 2860 | 80 |
WQK80-20-7.5QG | 80 | 20 | 7.5 | 380 | 50 | 2860 | 100 |
QX8-40-1.5 | 8 | 40 | 1.5 | 220/380 | 50 | 2860 | 50 |
QX10-35-2.2 | 10 | 35 | 2.2 | 380 | 50 | 2860 | 50 |
QX10-45-3 | 10 | 45 | 3 | 380 | 50 | 2860 | 50 |
QX12-50-4 | 12 | 50 | 4 | 380 | 50 | 2860 | 50 |
QX12.5-60-5.5 | 12.5 | 60 | 5.5 | 380 | 50 | 2860 | 50 |
QX15-68-7.5 | 15 | 68 | 7.5 | 380 | 50 | 2860 | 50 |
Pump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless St
See DetailsCONDITION 1.Medium temperature is not more than +40 DEGC2.Medium PH value between 6.5~8.53.Contain
See DetailsGA Series Self-Priming Peripheral Pumps The Automatic booster system consists of a water pump, an ai
See DetailsOperating Limits: Suction lift upto 9m Fluid temperature upto 60℃ Maximum ambient temperature40
See DetailsPerformance Range: Flow rate up to 1300L/min(7.2m2/h) Head upto22m Operating Limits: Suctio
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction
See DetailsZhejiang Shuyilin Electromechanical Co., Ltd. is a modern new-type water pumps manufacturing enterprise specializing in production, scientific research, development, sales and service.
