2、Medium pH value between 6.5~8.5
3.Containing solid impurities in the medium volume ratio of not more than 0.1%
4、Diving depth of up to 100m
5、Pump professional sewage pumping
The company firmly believes that science and technology are the primary productive forces. Rely on quality for survival, rely on technological innovation for development.
+86-18869976464 Contact Us(Model) | Flow (m³/h) |
Lift (m) |
Power (Kw) |
Voltage (V) |
Frequency (Hz) |
Rotating speed (r/min) |
Piping (mm) |
50JYWQD10-10-1000-0.75 | 10 | 10 | 0.75 | 220 | 50 | 1000 | 50 |
50JYWQ10-10-1000-0.75 | 10 | 10 | 0.75 | 380 | 50 | 1000 | 50 |
50JYWQD7-15-1200-1.1 | 7 | 15 | 1.1 | 220 | 50 | 1200 | 50 |
50JYWQ7-15-1200-1.1 | 7 | 15 | 1.1 | 380 | 50 | 1200 | 50 |
65JYWQD15-9-1200-1.1 | 15 | 9 | 1.1 | 220 | 50 | 1200 | 65 |
65JYWQ15-9-1200-1.1 | 15 | 9 | 1.1 | 380 | 50 | 1200 | 65 |
50JYWQD15-15-1200-1.5 | 15 | 15 | 1.5 | 220 | 50 | 1200 | 50 |
50JYWQ15-15-1200-1.5 | 15 | 15 | 1.5 | 380 | 50 | 1200 | 50 |
65JYWQD25-10-1200-1.5 | 25 | 10 | 1.5 | 380 | 50 | 1200 | 65 |
65JYWQ25-10-1200-1.5 | 25 | 10 | 1.5 | 380 | 50 | 1200 | 65 |
50JYWQ9-22-1600-2.2 | 9 | 22 | 2.2 | 380 | 50 | 1600 | 50 |
65JYWQ25-15-1600-2.2 | 25 | 12 | 2.2 | 380 | 50 | 1600 | 65 |
80JYWQ40-10-1600-2.2 | 40 | 10 | 2.2 | 380 | 50 | 1600 | 80 |
100JYWQ50-7-1600-2.2 | 50 | 7 | 2.2 | 380 | 50 | 1600 | 100 |
50JYWQ15-30-1600-3 | 15 | 30 | 3 | 380 | 50 | 1600 | 50 |
65JYWQ20-30-1600-4 | 20 | 30 | 4 | 380 | 50 | 1600 | 65 |
80JYWQ40-15-1600-4 | 40 | 15 | 4 | 380 | 50 | 1600 | 80 |
100JYWQ60-10-1600-4 | 60 | 10 | 4 | 380 | 50 | 1600 | 100 |
50JYWQ15-40-1600-5.5 | 15 | 40 | 5.5 | 380 | 50 | 1600 | 50 |
65JYWQ25-35-1600-5.5 | 25 | 35 | 5.5 | 380 | 50 | 1600 | 65 |
80JYWQ30-30-1600-5.5 | 30 | 30 | 5.5 | 380 | 50 | 1600 | 80 |
100JYWQ70-10-1600-5.5 | 70 | 10 | 5.5 | 380 | 50 | 1600 | 100 |
150JYWQ100-7-1600-5.5 | 100 | 7 | 5.5 | 380 | 50 | 1600 | 150 |
50JYWQ15-45-1600-7.5 | 15 | 45 | 7.5 | 380 | 50 | 1600 | 50 |
65JWYQ25-40-1600-7.5 | 25 | 40 | 7.5 | 380 | 50 | 1600 | 65 |
80JYWQ65-22-1600-7.5 | 65 | 22 | 7.5 | 380 | 50 | 1600 | 80 |
100JYWQ80-20-1600-7.5 | 80 | 20 | 7.5 | 380 | 50 | 1600 | 100 |
150JYWQ100-10-1600-7.5 | 100 | 10 | 7.5 | 380 | 50 | 1600 | 150 |
WQD6-16-0.75 | 6 | 16 | 0.75 | 220 | 50 | 2860 | 50 |
WQ6-16-0.75 | 6 | 16 | 0.75 | 380 | 50 | 2860 | 50 |
WQD8-18-1.1 | 8 | 18 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-18-1.1 | 8 | 18 | 1.1 | 380 | 50 | 2860 | 50 |
WQD8-16-1.1 | 8 | 16 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-16-1.1 | 8 | 16 | 1.1 | 380 | 50 | 2860 | 50 |
WQD8-26-1.1 | 8 | 26 | 1.1 | 220 | 50 | 2860 | 50 |
WQ8-26-1.1 | 8 | 26 | 1.1 | 380 | 50 | 2860 | 50 |
WQD10-16-1.1 | 10 | 16 | 1.1 | 220 | 50 | 2860 | 50 |
WQ10-16-1.1 | 10 | 16 | 1.1 | 380 | 50 | 2860 | 50 |
WQD12-18-1.5 | 12 | 18 | 1.5 | 220 | 50 | 2860 | 50 |
WQ12-18-1.5 | 12 | 18 | 1.5 | 380 | 50 | 2860 | 50 |
WQ015-18-1.5 | 15 | 18 | 1.5 | 220 | 50 | 2860 | 50 |
WQ15-18-1.5 | 15 | 18 | 1.5 | 380 | 50 | 2860 | 50 |
WQD8-20-1.5 | 8 | 20 | 1.5 | 220 | 50 | 2860 | 50 |
WQ8-20-1.5 | 8 | 20 | 1.5 | 380 | 50 | 2860 | 50 |
WQD15-15-1.5 | 15 | 15 | 1.5 | 220 | 50 | 2860 | 65 |
WQ15-15-1.5 | 15 | 15 | 1.5 | 380 | 50 | 2860 | 65 |
WQD30-10-1.5 | 30 | 10 | 1.5 | 220 | 50 | 2860 | 75 |
WQ30-10-1.5 | 30 | 10 | 1.5 | 380 | 50 | 2860 | 75 |
WQD8-40-1.5 | 8 | 40 | 1.5 | 220 | 50 | 2860 | 50 |
WQ8-40-1.5 | 8 | 40 | 1.5 | 380 | 50 | 2860 | 50 |
WQ10-30-2.2 | 10 | 30 | 2.2 | 380 | 50 | 3000 | 50 |
WQ15-32-2.2 | 15 | 32 | 2.2 | 380 | 50 | 3000 | 50 |
WQ20-25-2.2 | 20 | 25 | 2.2 | 380 | 50 | 3000 | 65 |
WQ30-15-2.2 | 30 | 15 | 2.2 | 380 | 50 | 3000 | 75 |
WQ15-36-3 | 15 | 36 | 3 | 380 | 50 | 3000 | 50 |
WQK10-10-0.75QG | 10 | 10 | 0.75 | 220/380 | 50 | 2860 | 50 |
WQK15-9-1.10G | 15 | 9 | 1.1 | 220/380 | 50 | 2860 | 50 |
WQK15-15-1.50G | 15 | 15 | 1.5 | 220/380 | 50 | 2860 | 50 |
WQK26-7-1.50G | 26 | 7 | 1.5 | 220/380 | 50 | 2860 | 80 |
WQK18-20-2.20G | 18 | 20 | 2.2 | 380 | 50 | 2860 | 50 |
WQK25-15-2.20G | 25 | 15 | 2.2 | 380 | 50 | 2860 | 65 |
WQK30-10-2.20G | 30 | 10 | 2.2 | 380 | 50 | 2860 | 80 |
WQK20-25-3QG | 20 | 25 | 3 | 380 | 50 | 2860 | 50 |
WQK30-16-3QG | 30 | 16 | 3 | 380 | 50 | 2860 | 65 |
WQK35-15-3QG | 35 | 15 | 3 | 380 | 50 | 2860 | 80 |
WQK40-13-3QG | 40 | 13 | 3 | 380 | 50 | 2860 | 100 |
WQK25-28-4QG | 25 | 28 | 4 | 380 | 50 | 2860 | 50 |
WQK32-20-4QG | 32 | 20 | 4 | 380 | 50 | 2860 | 65 |
WQK42-16-4QG | 42 | 16 | 4 | 380 | 50 | 2860 | 80 |
WOK50-12-4QG | 50 | 12 | 4 | 380 | 50 | 2860 | 100 |
WQK25-40-5.5QG | 25 | 40 | 5.5 | 380 | 50 | 2860 | 50 |
WQK40-28-5.5QG | 40 | 28 | 5.5 | 380 | 50 | 2860 | 65 |
WQK60-18-5.5QG | 60 | 18 | 5.5 | 380 | 50 | 2860 | 80 |
WQK80-10-5.5QG | 80 | 10 | 5.5 | 380 | 50 | 2860 | 100 |
WQK50-22-7.5QG | 50 | 22 | 7.5 | 380 | 50 | 2860 | 80 |
WQK80-20-7.5QG | 80 | 20 | 7.5 | 380 | 50 | 2860 | 100 |
QX8-40-1.5 | 8 | 40 | 1.5 | 220/380 | 50 | 2860 | 50 |
QX10-35-2.2 | 10 | 35 | 2.2 | 380 | 50 | 2860 | 50 |
QX10-45-3 | 10 | 45 | 3 | 380 | 50 | 2860 | 50 |
QX12-50-4 | 12 | 50 | 4 | 380 | 50 | 2860 | 50 |
QX12.5-60-5.5 | 12.5 | 60 | 5.5 | 380 | 50 | 2860 | 50 |
QX15-68-7.5 | 15 | 68 | 7.5 | 380 | 50 | 2860 | 50 |
Performance Range Flow rate up to 80L/min(4.8m2/h) Head upto 55m Operating Limits: Suction li
See DetailsCONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value between 6.5~8.53
See DetailsMaterial Casing:Cast lron Impeller:Brass Shaft:Crstainless lron MSeal:Carbon&Ceramic High-tempe
See DetailsPerformance Range: Flow rate up to 60L/min(3.6m/h) Operating Limits: Suction liftupto 9m Fl
See Details1. The volume ratio of solid impurities in the mecdium shall not exceed 0.1%, and the particle size
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Ste
See DetailsPerformance Range: Flow rate up to 80L/min(4.8m/h) Head upto 55m Operating Limits: Suction l
See DetailsCONDITION: 1.Medium temperature is not more than +40 DEGC2.Medium pH value between 6.5
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Stee
See DetailsPump Body:Cast iron Rotor Can:Stainless Steel Bearing:Ceramic/GraphiteImpeller:PP/Stainless Steel
See DetailsZhejiang Shuyilin Electromechanical Co., Ltd. is a modern new-type water pumps manufacturing enterprise specializing in production, scientific research, development, sales and service.
